• Peak Power 1300W
• PP X-motif Cone with Diamond Array Pattern
• Closed Yoke with Advanced Airflow Control
• Stress Controlled Spider
• Robust Thermal Management System

X-Motif Cone with Diamond Array Pattern
X-Motif Cone controls resonance frequency and cuts unnecessary frequency, delivering powerful and solid bass response.

Closed Yoke with Advanced Airflow Control
The KFC-W3041 has a robust thermal management system implemented. with an Aluminum Bobbin, Closed Yoke Design, and Advanced Airflow Control.

Stress Controlled Spider
Computer-optimized damper controls stress and increases mechanical durability.

The Best Match
KFC-W3041 subwoofer is precisely power matched with the KAC-D5101 amplifier.

Optional CA-121G Subwoofer Grille Ready

Specs

ELECTRICAL
Impedance (Ω)    4
Peak Input Power (W)    2000
RMS Power (W)    300
Sensitivity (dB at 1m)    85
Frequency Response (Hz)    29 ~ 300

MOUNTED SPEAKER
Size    300mm    12 inch
Diaphragm    Paper
Cap    Injection PP
Surround    Urethane
Basket    Steel
Gasket    ABS
Magnet    Ferrite    φ134-φ70-t30

DIMENSION
Width    326mm    12 - 13/16 inch
Height    326mm    12 - 13/16 inch
Cut-out Diameter    279mm    11 inch
Depth    155.4mm    6 - 1/8 inch
Mounting Depth    137mm    5 - 3/8 inch

WEIGHT
Woofer without Gasket    4.2 kg    9.3 lb
Gross Weight    5.0 kg    11.0 lb
Weight of Magnet    1560 g    54.9 oz

ACCESSORY    Instruction Manual, Warranty Card

SPECIAL FEATURE    Injection PP X-motif Cone with
Diamond Array Pattern
Closed Yoke with Advanced
Airflow Control
Aluminum Bobbin
